5K Questions! Won't idle, threads merged.

[Evan G]

32/36 jono, DERPPPP



whats your timing set at? if its around 15 degrees youll get it to idle low.



try a return spring, whats your idle jets?



thread about 5k whore

[5ksev]

I'm not sure what the spark timing is at, I'll hopefully buy a timing light tomorrow.. Also, I remember reading somewhere you can only get 8* out of the stock dizzy? Not sure if mine is stock or after market.. If someone could let me know, that would be good!



( will upload a pic in a min )

[Jono.C]

32/36 jono, DERPPPP



whats your timing set at? if its around 15 degrees youll get it to idle low.



try a return spring, whats your idle jets?



thread about 5k whore



:P :P Only looked at the bottom bit haha. Derp indeedy.

[5ksev]

is this a stock dizzy?



[Evan G]

pics of internals please. looks like a 5k elec one from the vac unit

[5ksev]

pics of internals please. looks like a 5k elec one from the vac unit

will get some tomorrow! :y:



also too, does anyone happen to have an image of how my vac lines connect up? since the day i got it, it had 2 little things coming off my what i think is, the thurmo housing? with nothing blocking them.. but yet its run fine? i just want to tidy them up... so yeah if anyone has a diagram or an image, that would be good!

[Evan G]

i don't run any vac advance. it makes my idle higher and timing goes thru the roof at idle.



its used for fuel eco on the fwy. i don't use it



edit - did you check your idle jets? what jet size you running?

Edited December 29, 2011 by Evan G

[B.L.Z.BUB]

What level is the threat now?





Sorry, couldn't help myself.

[Evan G]

severe is 4age

high is 5k turbo

elevated is worked 4k

guarded is standerd 3k

low is daily

[5ksev]

I'm not sure how to check the idle jet size?



It should be fine due to it running with this carby on it.. Right?

[Evan G]

have you used anyother websites as a source of information? ei google?





did you remove a fuel line? did a piece of junk fall in the fuel line?

[5ksev]

I don't normally look up how to do things untill I'm doing it.. So no..



And also yea, I took the entire carb off.. And sat it on the bench in the garage for a week.. So it could have gathered shit?

[cianw94]

Clean out your jets in your carb. I wouldn't worry about it until you set the timing up correctly as that could very likely be causing it. You're stock dizzy can be set at any degree of advance at idle. That is why you twist it so that you can have the ignition timing coming exactly when you want it to maximise power and fuel economy. When you say 8 degrees that is what Toyota recommend for fuel economy and emmissions. You can set it at whatever you thinbgs works best. Generally 10-15* BTDC. I found about 13 degrees BTDC was best. Are you sure your cam timing is correct? All marks/dimples lined up?

[5ksev]

Yeah pretty sure cam timing is right, as it drives perfect..



I lined it up dot to dot, then with head off I turned it over by crank, and as it #1 would go down, the exhaust lifter would lift.. So to fix this, I rotated the cam either 7 or 9 teeth, ( 1/4 of a full rev ) and by doing this, it then set the cam timing to, exhaust open whilst piston coming up, and shuts at tdc, then inlet is open whilst it goes back down.. Then does full combustion part..



Long story short, I'm fairly confident on the timing.. I'll speak to my mate ( mechanic ) tomorrow, and see if he has any ideas

[5ksev]

Also, how can I adjust my dizzy to what ever, then I can only loosen the bolt and spin it a little bit?
